This new-type Servo six color stack flexo printing machine is equipped with an automated unwinding system, enabling high-precision automated control of the entire process from unwinding to printing. Its wide printing format significantly increases single-pass output, perfectly meeting the needs of large-format printed products such as plastic packaging bags and film labels, making it an ideal choice for those seeking stable and diverse printing needs.
Technical Specifications
|
Model |
CH6-600S-S |
CH6-800S-S |
CH6-1000S-S |
CH6-1200S-S |
|
Max. Web Width |
650mm |
850mm |
1050mm |
1250mm |
|
Max. Printing Width |
600mm |
800mm |
1000mm |
1200mm |
|
Max. Machine Speed |
200m/min |
|||
|
Max. Printing Speed |
150m/min |
|||
|
Max. Unwind/Rewind Dia. |
Φ800mm |
|||
|
Drive Type |
Servo drive |
|||
|
Photopolymer Plate |
To be specified |
|||
|
Ink |
Water base ink or solvent ink |
|||
|
Printing Length (repeat) |
350mm-1000mm |
|||
|
Range Of Substrates |
LDPE, LLDPE, HDPE, BOPP, CPP, PET, Nylon, |
|||
|
Electrical Supply |
Voltage 380V. 50 HZ.3PH or to be specified |
|||
Video Introduction
Machine Features
1.This 6 color stack flexo printing machine adopts an advanced servo-driven system, achieving precise synchronization and registration control between color units, completely eliminating errors inherent in traditional mechanical transmission. Its high-precision anilox rollers, combined with an advanced ink delivery system, ensure consistent reproduction of vibrant colors and delicate gradients. Even continuous patterns on large formats are guaranteed to be free of color discrepancies and streaks.
2.The wide-format design of this stack flexo printing machine significantly enhances single-pass production capacity, making it particularly suitable for high-volume production of large-format products such as packaging bags, flexible packaging, and decorative substrates. The integrated fully automatic unwinding system enables quick job changeovers, greatly improving production efficiency. Its robust flexibility allows it to effortlessly handle various substrates, meeting diverse production needs.
3.The servo motors offer significant energy savings compared to traditional models, effectively reducing operational costs. The user-friendly control system simplifies operation, allowing operators to easily monitor and adjust all parameters via a touchscreen interface, reducing reliance on operator experience.
4.Additionally, this stack type flexographic printing machine is constructed with high-strength cast iron and precision components, ensuring structural stability. Even under high-speed, wide-format operating conditions, it effectively minimizes vibrations, guaranteeing long-term operational reliability. This rugged design ensures smooth and continuous production line operation, significantly reducing maintenance costs over the equipment's lifespan and ensuring long-term return on investment.
Detail Image
Printing Sample
