Gearless CI Flexographic Printing Machine

The Gearless CI Flexographic Printing Machine adopts full servo direct-drive technology, delivering higher printing precision and faster job changeover. Designed for diverse substrates-including paper, LDPE, BOPP, PET and other plastic films-it maintains vivid colors and steady registration even at high operating speeds. It also cuts energy consumption and material waste significantly, effortlessly boosting flexible packaging printing efficiency and quality to meet various industry needs.

Parameters

Material Feeding Diagram

This material feeding diagram clearly illustrates the complete printing path of films from unwinding to rewinding when the full servo gearless flexographic printing press is in operation. It intuitively demonstrates how materials pass through precision tension control and automatic web guiding systems, then travel smoothly through all gearless printing units, drying and cooling sections. This diagram helps you quickly grasp the smooth, compact material routing inside the equipment, which lays a solid foundation for high-efficiency, high-precision printing and reduced material waste.

Video Introduction

Machine Feature

1. Full Servo Gearless Drive for Precise, Controllable Registration

This 6 colour flexo printing machine uses full servo gearless independent drive-no traditional gear transmission, so gear wear and pitch errors are eliminated. It maintains ±0.1mm registration accuracy in steady operation, effectively removing ink bars while keeping dot reproduction sharp and color overprinting precise.

2. Sleeve Design to Boost Production Efficiency

Lightweight sleeve-type plate cylinders and anilox rollers let you change plates faster and safer, cutting job changeover and setup time to boost equipment utilization. It's a great fit for flexible multi-batch, short-run production needs.

3. Non-Stop Winding & Unwinding for Continuous Production

Equipped with non-stop winding and unwinding systems, the machine enables uninterrupted printing without pausing for roll changes. This design slashes downtime, ramps up throughput significantly, and maintains consistent material tension and registration-ideal for high-volume runs while minimizing material waste from unexpected stops.

4.High-Speed Stable Operation: Balancing Efficiency and Quality

Full servo drive cuts down vibration, so the Gearless CI Flexographic Printing Machine runs smoothly even at a top speed of 500m/min. Its modular hot air circulation drying system uses constant temperature control to dry ink fast, avoiding substrate deformation from overheating, ensuring uniform colors and improving print pass rate.

5.Wide-Width Compatibility for Diverse Film Substrates

It works with multiple film substrates like LDPE, BOPP and PET, fitting different printing size requirements. Coming with tension control and automatic web guiding, it keeps material feeding steady, preventing wrinkling and deviation to meet varied packaging demands.

Detail Image









Printing Sample

Our flexographic printing samples cover all common flexible packaging substrates, including paper as well as LDPE, BOPP, PET and CPP film materials. Each sample showcases sharp pattern edges, accurate color overprinting and high-precision dot reproduction-testament to this Gearless CI Flexographic Printing Machine's capabilities. They fully demonstrate the equipment's stable registration accuracy (±0.1mm) and excellent color fastness, meeting high-end packaging printing standards for food, daily use and other industries.









Packaging and Delivery

We offer professional, secure packaging for heavy-duty gear-fully guarding against transport risks so your gearless flexo printing machine arrives intact. Custom packaging consulting is available, tailored to your specific transport routes and environment.

For delivery, we team up with reputable heavy-machinery logistics providers for safe, standard loading, unloading and transit. Real-time full-process tracking keeps you in the loop timely, and all required supporting documents are supplied as needed. Post-delivery, we provide after-sales support such as on-site acceptance guidance, smoothing installation and commissioning for a worry-free whole process.



Our Patent Certificate

We hold key patents covering core flexo rinting machine technologies, fully compliant with intellectual property standards. These patents guarantee technical originality, boost equipment performance and competitiveness, and lend solid support to your global business development.

Why Choose Us?

• We don't just sell machines-we put together tailor-made flexo printing solutions that fit your unique production workflows and market needs perfectly.
• Having focused on flexible packaging printing for years, we really get industry pain points-delivering targeted, efficient production support.
• Our equipment meets international quality and safety standards, with full certification to help your business enter global markets smoothly.
• Our pre-sales and after-sales teams respond quickly-we offer technical consultation when you need it, and fast troubleshooting to cut downtime.
• We take orders of all sizes, from small-batch custom work to large-scale production, adapting easily to your changing business needs.
• Our equipment is smart and low-consumption-it cuts energy and material waste, boosting your profits while being eco-friendly.
• We've got plenty of global collaboration experience, with proven delivery and service across regions, so we understand your local logistics and compliance needs.
• We keep updating tech with customer feedback-tweaking functions to match market trends, keeping your production competitive.
• A dedicated one-on-one account manager-follows up the whole process, solving all concerns from consultation to long-term cooperation.
• Customized on-site training and debugging-tailored to your team's skill level, ensuring quick mastery and smooth startup.
