6 Colour Stack Type Flexo Printing Machine

MODEL:CH-B-Z Series
Machine Speed:120m/min
Number Of Printing Decks:4/6/8/10
Drive Method:Synchronous belt drive
Heat Source:Gas, Steam, Hot oil, Electrical heating
Electrical Supply:Voltage 380V. 50 HZ.3PH or to be specified
Main Processed Materials:Films;Paper; Non-Woven; Paper cup
Send Inquiry
Chat Now

Product Introduction

One of the key advantages of 6 Colour Stack Type Flexo Printing Machine is high-speed printing capabilities. With a range of advanced features, including automatic registration and color control, this machine can produce high-quality prints at a fast rate, making it an ideal solution for businesses that need to produce large volumes of printed materials.



product-800-600



Parameter



TECHNICAL SPECIFICATIONS

Model

CH6-600B-Z

CH6-800B-Z

CH6-1000B-Z

CH6-1200B-Z

Max. Web Width

650mm

850mm

1050mm

1250mm

Max. Printing Width

560mm

760mm

960mm

1160mm

Max. Machine Speed

120m/min

Max. Printing Speed

100m/min

Max. Unwind/Rewind Dia.

Φ1200mm/Φ1500mm

Drive Type

Synchronous belt drive

Photopolymer Plate

To be specified

Ink

Water base ink or solvent ink

Printing Length (repeat)

300mm-1300mm

Range Of Substrates

Paper,Non Woven,Paper Cup

Electrical Supply

Voltage 380V. 50 HZ.3PH or to be specified



Video Introduction





Machine Features



The stack flexo printing machine is a remarkable piece of technology that offers multiple benefits to the printing industry.



1. High-Quality Printing: The 6 Colour Stack Type Flexo Printing Machine offers excellent print quality offers excellent print quality, which is crucial in the printing industry. It is ideal for printing fine patterns and designs.



2. Efficient Production: Due to the stack type flexo printing machine multiple printing capabilities, it can produce more products in a shorter time frame. This feature is particularly beneficial for large-scale printing projects that require faster production times.



3. Versatile: The 6 colour stack flexo printing machine can print on a wide range of substrates, from paper to plastic, making it a versatile tool for the printing industry. This capability allows for the printing of different products such as labels, packaging, and promotional materials.



4. Cost-effective: Using the stack flexographic printing machine can significantly reduce printing costs. The machine's efficient production capability means that more products can be printed in a shorter time frame.



5. Environmentally friendly: The flexo printing machine uses water-based ink, which is more environmentally friendly than other types of ink.



Detail Image

01
02
03
04
05





06








Printing samples



01
02
03
04



05
06

FAQ



Q: What is a 6 Colour Stack Type Flexo Printing Machine?

A:A stack type flexo printing machine is a high-speed printing press that uses flexible polymer plates to transfer ink onto various materials. It is called a "stack" machine because it uses multiple printing units that are stacked on top of one another to achieve multicolored printing.



Q:Can a stack type flexo printing machine be customized to fit specific printing requirements?

A:Yes, stack type flexo printing machines can be customized to meet specific printing requirements. This includes adding additional printing stations, using special inks or coatings, and incorporating unique printing processes.
