Wenzhou Changhong Printing Machinery Co., Ltd. is one of the leading manufacturers and suppliers of non woven flexo printing machine in China. Welcome to buy cheap non woven flexo printing machine for sale here from our factory. Quality products and reasonable price are available.

The non woven flexo printing machine is a printing machine that uses photosensitive resin as a plate, which is widely used for printing film, roll paper, food packaging and other packaging materials.has accurate overprinting, small color difference, bright colors and rich layers. flexo printing machine color of the machine can be customized according to your requirements.

product-697-523

Parameter

TECHNICAL SPECIFICATIONS
Model	CHCI4-600J-NW	CHCI4-800J-NW	CHCI4-1000J-NW	CHCI4-1200J-NW
Max. Web Width	650mm	850mm	1050mm	1250mm
Max. Printing Width	600mm	800mm	1000mm	1200mm
Max. Machine Speed	250m/min
Max. Printing Speed	200m/min
Max. Unwind/Rewind Dia.	Φ1200mm/Φ1500mm
Drive Type	Central drum with Gear drive
Photopolymer Plate	To be specified
Ink	Water base ink or solvent ink
Printing Length (repeat)	350mm-900mm
Range Of Substrates	Paper,Non Woven,Paper Cup
Electrical Supply	Voltage 380V. 50 HZ.3PH or to be specified

Video Introduction

Below is the workflow of the non woven flexo printing machine

Technical Features

1. Ci flexo printing machine automate product quality management, and complete the production of high-quality products under the state of human-computer interaction;

2. High-speed, high-efficiency, large-scale production suitable for large-scale orders, is a powerful weapon for large-scale printing plants to improve market competitiveness;

3. Less waste of machine adjustment, high printing speed, high output efficiency;

4. Relatively simple maintenance and high safety performance.

Detail Image

Printing Precautions

1. Sharp parts, such as the cutter at the winding and unwinding place, the scraper of each unit, etc.

2. The occlusion between the rotating parts and the tangential moving parts, such as the power transmission belt pulley of each motor of the printing press (air intake fan, main motor, winding and unwinding machine), the lifting rack and gear of each unit ink tray, etc.

3. The occlusion of the opposing rotating parts is generally called the nip point, such as gears, rubber rollers, guide rollers, etc. The bite point is the highest accident risk area on a gravure printing press, and employees need to be extra careful when working there. There have been several cases of a printing press being bitten by the bite point and biting a finger or palm. The main bite points are: the bite point between the feeding and cutting knife sticking roller and the roll film, the bite point between the guide roller and the guide roller, the bite point between the feeding and traction roller, the bite point between the cooling roller and the back pressure roller, and the embossing rubber roller. The bite point with the plate roller, the bite point between the ink transfer roller and the plate roller, the bite point at the discharge traction roller, the bite point between the receiving pressure roller and the roll film, etc.

4. Rotating shafts, including connectors, mandrels, chucks, leadscrews and rods, etc. Such as flexo printing machine retractable reel and chuck, main drive shaft and so on.

Printing Sample
